Articulating Pivoting Wall Mount for 13" - 37" TVs

Articulating Wall Mount for 13in to 37in TVs

Alternative Views:

List Price: $119.99

Our Price: $81.99

Availability:: Usually Ships in 24 Hours
Product Code: CRIM-SMALL-1337

Description

Wall Mount Overview

Swinging arm holds 13" - 37" screens 2.8” from wall and extends up to 7.9”. Smooth tilt adjustments of 15° forward and 5° back with a locking knob for a variety of viewing angles. 5° side to side roll for perfect screen positioning. Makes a secure installation quick and easy, simply hang the screen and turn the pre-assembled securing screw to lock in place. Integrated cable management for clean look. Great for use in the home, hospitals, hotels and many other business applications.

VESA compatible 75x75mm, 100x100mm, 200x100mm, 200x200mm
Pre-assembled securing screw makes installation fast and easy
Post installation screen leveling without use of tools
Integrated cable management for clean look
UL Approved
Landscape orientation

Features

Technical Description

TV size range 13” – 37”
Weight capacity 80lb (36kg)
Max mounting pattern 200x200mm
VESA mounting patterns 75x75mm, 100x100mm, 200x100mm, 200x200mm
Depth from wall 2.8” (72mm)
Max extension 7.9” (200mm)
Tilt +15°/-5 Pivot 180° 180° (based on TV width)
Roll (side to side) 5°
Mounting surface wood stud, concrete or cinder block
Stud spacing single stud single stud
Construction aluminum/high-grade cold rolled steel
Product finish scratch resistant epoxy powder coat
Color black
Manufacturer Warranty 10-years
